Live activities

A live activity is something ongoing or short-lived that a module shows in the compact pill: a timer counting down, a song playing, a build running. Several can run at once, from different modules. The framework decides which one holds the pill and draws the pill, the peek, the capsules beside it, and their motion; an activity only supplies views.

Two live activities in the compact pill: a song holds it, with its cover left of the notch and its bars right of it, and a focus timer waits in a small capsule beside it. Next to that, the same pill grown into the song’s peek, with its title, artist and progress

Starting one

Each module gets its own view of the host’s activities, NookLiveActivities. Resolve it from the module’s services, or read \.nookLiveActivities in a view.

let activities = context.services.resolve(NookLiveActivitiesKey.self)

var focus = NookLiveActivity(id: "focus", accessibilityLabel: "Focus session") {
    Image(systemName: "flame.fill").foregroundStyle(.orange)       // left of the notch
} compactTrailing: {
    TimerText(timer: timer)                                         // right of the notch
} minimal: {
    FocusRing(timer: timer)                                         // the capsule
}
focus.setPeek { FocusPeek(timer: timer) }           // optional: the pill grows to show it
focus.setExpanded { FocusDetail(timer: timer) }     // optional: what the nook opens onto
activities.start(focus)

The views read the module’s own state, so the timer ticks in place. Starting another activity with the same id replaces it without moving it. end(_:after:) ends one, now or later, and endAll() ends every activity the module runs.

Keep compact content to a symbol and one short value. Text belongs in the peek.

A cover or a timer that appears in the pill and again in the peek or the expanded view can move between them instead of fading: mark it with nookSharedElement(_:style:) on each side. See Shared elements.

Who holds the pill

The running activities are ordered by:

their priority (.low, .normal, .high), highest first;
then an activity whose alert is showing;
then the most recently started.

No activities: the module’s own compact slots, as before.
One activity: its compactLeading and compactTrailing replace them.
Two or more: the first keeps the pill, and the next show their minimal view in capsules beside it. When more run than show, the last capsule counts the rest.

NookHostConfiguration.activityPolicy sets how many capsules show (one by default; zero shows none) and on which side:

host.activityPolicy = NookActivityPolicy(capsules: 2, side: .leading)

Alerts

An activity can call for attention when it starts, or later with alert(_:_:):

Alert	What happens
`.none` (default)	It only appears in the pill
`.peek(duration)`	The pill grows into the activity’s peek for that long
`.expand(duration)`	The nook opens onto the activity’s expanded view for that long

activities.alert("song", .peek(.seconds(3)))   // a new song

Alerts are surface claims, so they wait while the person is using the nook, and a higher priority alert preempts a lower one. An activity with no peek opens the nook instead of peeking. From a module that is not in front, only a .high priority alert takes the surface; a lower one updates the pill and nothing more.

Peek and the expanded view

With “Peek first” chosen in Settings (see Hover and peek), hovering the pill shows the peek of the activity holding it, or the module’s own peek when that activity has none. A click, or resting on the peek, opens the nook onto the activity’s expanded view under a breadcrumb with the activity’s label; the back glyph returns to the module’s home. Opening the nook any other way shows the module’s home, as always.

Lifetimes and modules

lifetime: .transient(duration) ends an activity on its own; .ongoing (the default) lasts until the module ends it.
When a module is unloaded (the default .unloadOnSwitchAway policy, on a switch), its activities end, since their views read state that is gone. A module whose activities should outlive a switch uses .stayResident.
NookModuleDescriptor.loadsAtLaunch builds a resident module at launch and gives it its onReady, so it can run activities from the background before it is ever shown.

Try it

swift run ShowcaseNook --scene compact   # the song in the pill, the focus session in a capsule
